Product Info
This product is EOL. Please see NAC EOL Notice for Cissoid.pdf
For more information or contact sales@nacsemi.com
- General Description
The CHT-OPA is a general-purpose quad operational amplifier for applications over the temperature range from -55 to 225°C.
The CHT-OPA can operate with both single and symmetrical power
Electrical Characteristics
| Additional Feature | ALSO OPERATES AT 5V SUPPLY |
| Family | TTL/H/L |
| JESD-30 Code | R-CDIP-T14 |
| Length | 18.99 |
| Logic IC Type | NAND GATE |
| Number of Functions | 4 |
| Number of Inputs | 2 |
| Number of Terminals | 14 |
| Package Body Material | CERAMIC, METAL-SEALED COFIRED |
| Package Code | DIP |
| Package Shape | RECTANGULAR |
| Package Style | IN-LINE |
| Peak Reflow Temperature (Cel) | NOT SPECIFIED |
| Seated Height-Max | 3.36 |
| Supply Voltage-Max (Vsup) | 3.63 |
| Supply Voltage-Min (Vsup) | 2.97 |
| Supply Voltage-Nom (Vsup) | 3.3 |
| Surface Mount | NO |
| Technology | TTL |
| Terminal Form | THROUGH-HOLE |
| Terminal Pitch | 2.54 |
| Terminal Position | DUAL |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED |
| Width | 7.62 |
