Product Info
This product is EOL. Please see NAC EOL Notice for Cissoid.pdf
For more information or contact sales@nacsemi.com
- General Description
The CHT-AMATHEA is a Medium Power 80V/3A dual-diode designed to achieve high performance in an extremely wide temperature range: typical operation temperature goes from -55°C to 225°C. 3 pr
Electrical Characteristics
| Family | TTL/H/L |
| JESD-30 Code | R-CDIP-T16 |
| JESD-609 Code | e4 |
| Length | 18.99 |
| Logic IC Type | D FLIP-FLOP |
| Number of Bits | 1 |
| Number of Functions | 2 |
| Number of Terminals | 16 |
| Output Polarity | COMPLEMENTARY |
| Package Body Material | CERAMIC, METAL-SEALED COFIRED |
| Package Code | DIP |
| Package Shape | RECTANGULAR |
| Package Style | IN-LINE |
| Peak Reflow Temperature (Cel) | NOT SPECIFIED |
| Propagation Delay (tpd) | 45 |
| Seated Height-Max | 3.36 |
| Supply Voltage-Max (Vsup) | 5.5 |
| Supply Voltage-Min (Vsup) | 2.97 |
| Supply Voltage-Nom (Vsup) | 3.3 |
| Surface Mount | NO |
| Technology | TTL |
| Terminal Finish | GOLD |
| Terminal Form | THROUGH-HOLE |
| Terminal Pitch | 2.54 |
| Terminal Position | DUAL |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED |
| Trigger Type | POSITIVE EDGE |
| Width | 7.62 |
| fmax-Min | 16 |
