- General Description
CHT-PLUTO-C1220 is a high temperature 1200V/20A Silicon Carbide module including one MOSFET switch and one Schottky diode in a single hermetic package. It is suitable to implement an asynchronous b
Electrical Characteristics
| Analog IC - Other Type | THREE TERMINAL VOLTAGE REFERENCE |
| JESD-30 Code | O-XBCY-W3 |
| Number of Functions | 1 |
| Number of Outputs | 1 |
| Number of Terminals | 3 |
| Output Voltage-Nom | 2.5 |
| Package Body Material | UNSPECIFIED |
| Package Shape | ROUND |
| Package Style | CYLINDRICAL |
| Peak Reflow Temperature (Cel) | NOT SPECIFIED |
| Supply Voltage-Max (Vsup) | 17.5 |
| Supply Voltage-Min (Vsup) | 4.5 |
| Surface Mount | NO |
| Temp Coef of Voltage-Max | 888 |
| Terminal Finish | NICKEL |
| Terminal Form | WIRE |
| Terminal Position | BOTTOM |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED |
| Trim/Adjustable Output | NO |
