Product Info
This product is EOL. Please see NAC EOL Notice for Cissoid.pdf
For more information or contact sales@nacsemi.com
- General Description
The CMT-OPA is a general-purpose quad operational amplifier for applications over the temperature range from -55 to +175°C. This circuit is fabricated using a CMOS SOI process, assuring latchup-fre
Electrical Characteristics
| Input Voltage-Max | 22.5 |
| Input Voltage-Min | 3.5 |
| JESD-30 Code | R-MSFM-T3 |
| Number of Functions | 1 |
| Number of Terminals | 3 |
| Operating Temperature, TJ-Max | 225 |
| Operating Temperature, TJ-Min | -55 |
| Output Current1-Max | 1 |
| Output Voltage1-Nom | 2.5 |
| Package Body Material | METAL |
| Package Shape | RECTANGULAR |
| Package Style | FLANGE MOUNT |
| Peak Reflow Temperature (Cel) | NOT SPECIFIED |
| Regulator Type | FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR |
| Surface Mount | NO |
| Technology | CMOS |
| Terminal Finish | NICKEL |
| Terminal Form | THROUGH-HOLE |
| Terminal Position | SINGLE |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED |
