Ordering Info
In Stock: 0
MOQ: 5
Lead Time: 14 weeks
Package Quantity: 5
HTS Code: 8542.39.00.00
ECCN: EAR99
COO: BE
Subject to tariff fees.
*Product Country of Origin (COO) information may be unavailable at the time of order placement. Buyer acknowledges that additional duties, tariffs, or import fees may be assessed based on the actual COO once determined.
| Quantity | Cost |
|---|---|
| 5 | - |
Product Info
This product is EOL. Please see NAC EOL Notice for Cissoid.pdf
For more information or contact sales@nacsemi.com
- General Description
The CHT-LDOS is a 1A, low-dropout linear voltage regulator compatible with hightemperature environments. Typical operation temperature range extends from -55°C to 225°C.
The circuit
Electrical Characteristics
| Analog IC - Other Type | SWITCHING CONTROLLER |
| Control Mode | VOLTAGE-MODE |
| Control Technique | PULSE WIDTH MODULATION |
| Height-Max (Seated) | 3.87 |
| Input Voltage-Max | 30 |
| Input Voltage-Min | 6 |
| Input Voltage-Nom | 7 |
| JESD-30 Code | R-CDIP-T28 |
| JESD-609 Code | e4 |
| Length | 35.56 |
| Number of Functions | 1 |
| Number of Terminals | 28 |
| Output Voltage-Nom | 5 |
| Package Body Material | CERAMIC, METAL-SEALED COFIRED |
| Package Code | DIP |
| Package Shape | RECTANGULAR |
| Package Style | IN-LINE |
| Peak Reflow Temperature (Cel) | NOT SPECIFIED |
| Surface Mount | NO |
| Switcher Configuration | PUSH-PULL |
| Switching Frequency-Max | 700 |
| Terminal Finish | GOLD |
| Terminal Form | THROUGH-HOLE |
| Terminal Pitch | 2.54 |
| Terminal Position | DUAL |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED |
| Width | 15.24 |
