- General description
The CHT-PMOS30xx is a family of high voltage P-channel power MOSFET's designed to achieve high performance in an extremely wide temperature range: typical operation temperature goes from -55&de
Electrical Characteristics
| Case Connection | ISOLATED |
| Configuration | SINGLE WITH BUILT-IN DIODE |
| DS Breakdown Voltage-Min | 80 |
| FET Technology | METAL-OXIDE SEMICONDUCTOR |
| JEDEC-95 Code | TO-254 |
| JESD-30 Code | S-MSFM-P3 |
| Number of Elements | 1 |
| Number of Terminals | 3 |
| Operating Mode | ENHANCEMENT MODE |
| Package Body Material | METAL |
| Package Shape | SQUARE |
| Package Style | FLANGE MOUNT |
| Peak Reflow Temperature (Cel) | NOT SPECIFIED |
| Polarity/Channel Type | N-CHANNEL |
| Pulsed Drain Current-Max (IDM) | 7.5 |
| Surface Mount | NO |
| Terminal Finish | NICKEL |
| Terminal Form | PIN/PEG |
| Terminal Position | SINGLE |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED |
| Transistor Application | SWITCHING |
| Transistor Element Material | SILICON |
