Product Info
This product is EOL. Please see NAC EOL Notice for Cissoid.pdf
For more information or contact sales@nacsemi.com
- General Description
The CHT-MOON is a dual, high-voltage Nchannel MOSFET in a very dense CSOIC16 SMD package. It is designed to achieve high performance in an extremely wide temperature range: typical operation temper
Electrical Characteristics
| Amplifier Type | OPERATIONAL AMPLIFIER |
| Average Bias Current-Max (IIB) | 0.01 |
| Common-mode Reject Ratio-Nom | 86 |
| Input Offset Voltage-Max | 8000 |
| JESD-30 Code | R-CDSO-G16 |
| JESD-609 Code | e4 |
| Length | 10.45 |
| Number of Functions | 4 |
| Number of Terminals | 16 |
| Package Body Material | CERAMIC, METAL-SEALED COFIRED |
| Package Code | HSOP |
| Package Shape | RECTANGULAR |
| Package Style | SMALL OUTLINE, HEAT SINK/SLUG |
| Peak Reflow Temperature (Cel) | NOT SPECIFIED |
| Slew Rate-Nom | 1.2 |
| Sub Category | Operational Amplifier |
| Supply Voltage Limit-Max | 25 |
| Supply Voltage-Nom (Vsup) | 10 |
| Surface Mount | YES |
| Terminal Finish | GOLD |
| Terminal Form | GULL WING |
| Terminal Pitch | 1.27 |
| Terminal Position | DUAL |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED |
| Unity Gain BW-Nom | 1500 |
| Width | 7.45 |
