Thank you for your inquiry. We are working on your request and will respond as soon as possible. For immediate inquiries please call 1-866-651-2901
Ordering Info
In Stock: 1
MOQ: 5
Lead Time: 12 weeks
Package Quantity: 5
HTS Code: 8542.39.00.00
ECCN: EAR99
COO: BE
Subject to tariff fees.
*Product Country of Origin (COO) information may be unavailable at the time of order placement. Buyer acknowledges that additional duties, tariffs, or import fees may be assessed based on the actual COO once determined.
| Quantity | Cost |
|---|---|
| 5 | - |
Product Info
This product is EOL. Please see NAC EOL Notice for Cissoid.pdf
For more information or contact sales@nacsemi.com
- General Description
The CHT-LDOS is a 1A, low-dropout linear voltage regulator compatible with hightemperature environments. Typical operation temperature range extends from -55°C to 225°C.
The circuit
Electrical Characteristics
| Interface IC Type | INTERFACE CIRCUIT |
| JESD-30 Code | R-CDSO-G28 |
| Length | 17.9 |
| Number of Functions | 2 |
| Number of Terminals | 28 |
| Package Body Material | CERAMIC, METAL-SEALED COFIRED |
| Package Code | HSOP |
| Package Shape | RECTANGULAR |
| Package Style | SMALL OUTLINE, HEAT SINK/SLUG |
| Peak Reflow Temperature (Cel) | NOT SPECIFIED |
| Seated Height-Max | 2.365 |
| Supply Voltage-Max | 5.25 |
| Supply Voltage-Min | 4.75 |
| Supply Voltage-Nom | 5 |
| Supply Voltage1-Max | 30 |
| Supply Voltage1-Min | 5 |
| Supply Voltage1-Nom | 15 |
| Surface Mount | YES |
| Terminal Form | GULL WING |
| Terminal Pitch | 1.27 |
| Terminal Position | DUAL |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED |
| Width | 7.45 |
