CISSOID EVK-PLA1050B-74
SiC Inverter Reference Design - Based on 3-Phase 1200V/550A SiC Inverter Control Module (CXT-ICM3SA12550AA (pin fin)) - 650 VDC / 275 Arms / 150 kW
Ordering Info
In Stock: 0
MOQ: 1
Package Quantity: 1
HTS Code: 8541.29.00.95
ECCN: EAR99
Subject to tariff fees.
*Product Country of Origin (COO) information may be unavailable at the time of order placement. Buyer acknowledges that additional duties, tariffs, or import fees may be assessed based on the actual COO once determined.
| Quantity | Cost |
|---|---|
| 1-4 | $18,514.29 |
| 5+ | $18,000.00 |
Secure Payment Methods:
Need more Info?
Product Info
Key Features
- Modular SiC power module
- Robust SiC gate driver board
- OLEA® T222 FPCU controller
- Advanced control algorithms
- SVPWM or DPWM up to 50kHz
- Low-ESL DC-Link capacitor
- DC & phase current sensors
- EMI filter & liquid cooling
- DC bus voltage (operating): 100-650V
- Max DC bus voltage (non-operating): 700V
- Continuous motor current: 275Arms
- Motor current peak (60s): 290Arms
- Continuous output power: 150kW
- Output power peak (60s): 180kW
