Ordering Info
In Stock: 95
Available: 56503 Delivery
MOQ: 1
Lead Time: 2 weeks
Package Quantity: 1
HTS Code: 8541210080
ECCN: EAR99
COO: US
| Quantity | Cost |
|---|---|
| 1-99 | $7.39 |
| 100-999 | $7.03 |
| 1000+ | $6.68 |
Secure Payment Methods:
Need more Info?
Electrical Characteristics
| Configuration | SEPARATE, 2 ELEMENTS |
| FET Technology | JUNCTION |
| Feedback Cap-Max (Crss) | 1.2 |
| JESD-30 Code | R-PDSO-G6 |
| JESD-609 Code | e3 |
| Moisture Sensitivity Level | 1 |
| Number of Elements | 2 |
| Number of Terminals | 6 |
| Operating Mode | DEPLETION MODE |
| Operating Temperature-Max | 150 |
| Package Body Material | PLASTIC/EPOXY |
| Package Shape | RECTANGULAR |
| Package Style | SMALL OUTLINE |
| Peak Reflow Temperature (Cel) | 260 |
| Polarity/Channel Type | N-CHANNEL |
| Qualification Status | Not Qualified |
| Surface Mount | YES |
| Terminal Finish | Matte Tin (Sn) |
| Terminal Form | GULL WING |
| Terminal Position | DUAL |
| Time@Peak Reflow Temperature-Max (s) | 40 |
| Transistor Element Material | SILICON |
